1. UA Precision Portable Colorimeter
Model : UA Series
Based on the colorimetric principle, the UA Precision Portable Colorimeter adopts high-precision filter system and two-color ABS injection shell, which have an great improvement in optical performance and waterproof rating. The analyzer can be widely used in laboratory and field water quality detection, Such as monitor the residual disinfectant in the disinfection process of municipal water supply, sewage treatment and other industries.
Model | UA-100 |
Items | Free Chlorine-LR(0.01-2.50mg/L) Free Chlorine-HR(0.1-10.0mg/L) |
Power Supply | 2 AA alkaline batteriesUSB powered | |
Operating Conditions | 0~50 ℃; 0~90% relative humidity (non-condensing) | |
Cuvette Cell | 25mm round cuvettes, 10mm square cuvettes | |
Communication Interface | USB, Bluetooth | |
Memory | 100 Records (automatically save the latest testing data) | |
Waterproof Rating | IP67 | |
Certification | CE |
Model | UA-200 |
Items | Free Chlorine-LR(0.01-2.50mg/L) Chlorine Dioxide-LR(0.02-5.00mg/L) |
Power Supply | 2 AA alkaline batteriesUSB powered | |
Operating Conditions | 0~50 ℃; 0~90% relative humidity (non-condensing) | |
Cuvette Cell | 25mm round cuvettes, 10mm square cuvettes | |
Communication Interface | USB, Bluetooth | |
Memory | 100 Records (automatically save the latest testing data) | |
Waterproof Rating | IP67 | |
Certification | CE |
===================================================================
===================================================================
The algorithm of 90° scattering which not only makes the measurement of low turbidity more stable, but also realizes wide testing ranges for the instrument (low, middle and high measuring ranges).Precise design of optics systemand signal amplification technique ensure the stability of date with high sensitivity.
Method | Scattering (90°) |
Range | 0-1000NTU |
Accuracy | ±5% |
Repeatability | ≤1% |
Resolution | 0.01NTU(Low range) |
Detector | Silicon photodiode |
Calibration mode | Support custom |
Power supply | 2AA alkaline batteries |
Operating conditions | 15 to 35 °C; 0 to 90% relative humidity (noncondensing) |
Storage conditions | -25 to 50 °C(instrument) |
Dimensions(W*L*H) | 160 x 62 x 30mm |
Weight | 150g |
Certification | CE |
.
===================================================================
===================================================================
Q-CL501B portable colorimeter is a detection instrument that can detect free chlorine, total chlorine, and combined chlorine. It is also a real portable instrument which is suitable for field work as it has light weight and external batteries. Default standard curve and EPA based methods ensure the accuracy of testing result, thus it can be used in laboratory testing.It is widely used in the field of water disinfection monitoring.
Specification :
Testing items | Free chlorine,Total Chlorine, Combined Chlorine |
Testing range | Free Chlorine : 0.01-5.00mg/L |
Total Chlorine: 0.01-5.00mg/L | |
Combined Chlorine:0.01-5.00mg/L | |
Precision | ±3% |
Testing Method | DPD spectrophotometry |
Weight | 150g |
Standard | USEPA (20th edition) |
Power supply | Two AA batteries |
Operating Temperature | 0-50°C |
Operating Humidity | Max 90 % relative humidity (non-condensing) |
Dimension (L×W×H) | 160 x 62 x 30mm |
Certificate | CE |
.
.
..
.
.
.
